Round Baghouse Filters

Introducing BETH Round Baghouse Filters, engineered with robust welded construction for exceptional pressure resistance, making them perfect for demanding applications. Designed for convenience, the filter bags are easily installed and removed from the clean gas side, accessible via a manhole.

Our standard series of Round Baghouses offer a wide range of filter surfaces, from 2.5 m² to 534 m² (27 to 5,748 sq.ft.), with custom solutions available for even larger filtration needs. Experience high-performance filtration tailored to your specifications.

Key features

• Standardized units covering a wide range in airflow, from approx. 2,700 Am3/h up to 53,400 Am3/h (1,590 ACFM – 31,400 ACFM)
• Achieve ultra-low emissions with consistently delivering residual dust levels below 10 mg/m³ (0.0044 grain/ft³). In suitable applications, options are available for achieving less than 5 mg/m3
• High under pressure resistance up to 1 bar
• High Explosion Pressure Resistant up to 13 bar
• Proven durability with a robust design built to last
• Cost-effective solution, with low investment, installation, operational, and maintenance costs thanks to modular construction, optimized airflow, minimal pressure drop and compressed air consumption
