Horizontal Baghouse Filters

Introducing the BETH Horizontal Filter Series – the ideal solution for space-constrained environments, particularly those with height limitations. With filter surface options ranging from 32 m² to 178 m² (345 sq.ft. to 1,916 sq.ft.), these compact yet powerful units are designed for maximum efficiency.

Our advanced design ensures that dust-laden air is evenly distributed across the filter area for optimal separation, thanks to a deflector plate and distribution chamber. Plus, with the continuous, automated cleaning powered by our Jet Pulse system, your filtration process runs seamlessly without any interruptions.

Maximize performance in limited space with BETH Horizontal Filters.

Key features

• Standardized units covering a wide range in airflow, from approx. 3,200 Am3/h up to 17,800 Am3/h (1,880 ACFM – 10,400 ACFM)
• Achieve ultra-low emissions with consistently delivering residual dust levels below 10 mg/m³ (0.0044 grain/ft³). In suitable applications, options are available for achieving less than 5 mg/m3
• Ultra-compact for space-constrained environments where every inch counts
• Proven durability with a robust design built to last
• Cost-effective solution, with low investment, installation, operational, and maintenance costs thanks to modular construction, optimized airflow, minimal pressure drop and compressed air consumption
• High spare part availability and reliable service to keep your system running smoothly
